NT855 Marine Main Engines Basic information

Engine Type:6 – Cylinder; In – line; 4 – Cycle
Displacement:14 L
Rated Speed:1600 – 2100 RPM
Advertised Power:147 – 450 HP @ 1600 – 2100 RPM
Peak Torque:1044 – 1491 N.m @ 1300 – 1500 RPM
Aspiration Method:Turbocharged & Water – Air Intercooler
Dry Weight:1258 – 1303 kg
Packing Size (L * W * H):1534 mm * 781 mm * 1355 mm
Contact us
CHONGQING CUMMINS

CCEC NT855 Marine Main Engines Detailed information

The CCEC NTA855-M series marine main engine is designed for diverse marine applications. Here are its key features:
Key Specifications:
Engine Type: 6-cylinder inline
Displacement: 14 liters
Bore: 140 mm (5.5 in)
Stroke: 152 mm (6.0 in)
Fuel System: PT Fuel System
Turbocharger: Equipped for enhanced performance
Power Range: 147 HP to 450 HP (110 kW to 336 kW)
Torque Range: 1044 N.m to 2612 N.m
Configurations:
T: Turbocharged
TA: Turbocharged with water-air intercooler
TAA: Turbocharged with air-air intercooler
Cooling Options:
Heat Exchanger Cooling
Keel Cooling
Services:
SeaMac offers support throughout the engine’s lifecycle:
Design and power system supply
Installation and commissioning
Training and after-sales service
Spare parts and technical support
Applications:
The engine suits marine propulsion and auxiliary power, providing flexible options for various needs.
Let me know if you need more information!

NT855 Marine Main Engine Details

Engine ModelAspirationRPRIMERPM
NT855 – M147Turbocharged147 HP @ 1600 RPM1600
NT855 – M220Turbocharged220 HP @ 1800 RPM1800
NT855 – M250Turbocharged250 HP @ 1800 RPM1800
NT855 – M300Turbocharged300 HP @ 1800 RPM1800
NTA855 – M400AWater – Air Intercooler400 HP @ 1800 RPM1800
NTA855 – M450Water – Air Intercooler450 HP @ 1800 RPM1800
NT855 – M200Turbocharged200 HP @ 1800 RPM1800
NT855 – M240Turbocharged240 HP @ 1800 RPM1800
NT855 – M270Turbocharged270 HP @ 1800 RPM1800
NTA855 – M350Water – Air Intercooler350 HP @ 1800 RPM1800
NTA855 – M400BWater – Air Intercooler400 HP @ 2100 RPM2100
