Caterpillar C27 858 KW Diesel Engine
| Engine Model | C27 858KW |
| Maximum power: | 858 KW |
| Peak Torque: | 5255 Nm @ 1400 rpm |
| Type | V12 |
| Rated speed | 1800-2000 rpm |
| Minimum power | 597 KW |
| Emissions | U.S. EPA Tier 4 Final |
| Bore * Stroke | 137.2 mm * 152.4 mm |
| Packing Size (L * W * H) | 1874mm * 1600mm * 1370mm |
| Lead Time: | 5-15 Working Days |
General Infomation of C27 858KW Diesel Engine
| General Infomation of C27 858KW Diesel Engine | |
| Engine Model | C27 858KW |
| Maximum Power | 858 kW |
| Maximum Torque | 5255 Nm @ 1400 rpm |
| Rated Speed | 1800 rpm |
| Minimum Power | 597 kW |
| Emissions | EU Stage V |
| Engine Configuration | V-12 |
| Bore | 137.2 mm |
| Stroke | 152.4 mm |
| Displacement | 27 l |
| Compression Ratio | 16.0:1 |
| Intake Method | Twin turbocharged aftercooled (TTA) |
| Combustion System | Direct Injection |
| Rotation (from Flywheel End) | Counterclockwise |
| Aftertreatment Devices | DOC+DPF or DOC+DPF+SCR |
| Length | 1874mm |
| Width | 1600mm |
| Height | 1370mm |
| Dry weight – basic operating engine, without optional accessories | 3004 kg |
C27 858KW Diesel Engine Standard Equipment
C27 Standard Equipment
Intake System
Twin Turbocharged with Aftercooling
Air-to-Air Aftercooling
Control System
Electronic Speed Control, PTO Speed Control
Programmable Power Ratings
Automatic Altitude Compensation
Fuel Temperature Power Compensation
Programmable Low and High Idle Speeds and Maximum Engine Speed Limits
Electronic Diagnostics and Fault Logger
Engine Monitoring System, SAE J1939 Broadcast and Control Unit
ADEM™ A4 Electronic Control Unit (ECU)
Cooling System
Thermostat and Housing, Vertical Outlet
Centrifugal Jacket Water Pump
Water Pump, Inlet
Exhaust System
Dry Exhaust Manifold
Optional Exhaust Port
Flywheel and Flywheel Housing
SAE No. 1 Flywheel Housing
Fuel System
MEUI Injection
Fuel Filter (2 Micron)
ACERT™ Technology
Fuel transfer pump
Fuel priming pump
Lubrication system
Crankcase breather
Oil cooler
Oil inlet
Lubricating oil filter
Front sump oil pan
Oil dipstick
Gear-driven oil pump
Universal
Shock absorber
Lifting eye
-20°C (-4°F) cold start aid
Paint: Caterpillar yellow, optional colors available upon request
